Features:
1. Special hanging parts ensure simple, safe and convenient installation.
2. The hanging angle of the box is from 0 to 12 degrees, and each variable is 1 degree, which can expand the entire line array into a large enough arc.
3. HL10B integrates low-distortion sound reinforcement technology, linear power amplifier technology and DSP digital audio processing technology. The input signal must first be processed by the pre-stage, then distributed by the DSP digital audio processor, and finally passed by the post-stage power amplifier. output to subwoofer and full-range speakers.
4 Excellent frequency response contributes to the high-fidelity reproduction effect and good sound field coverage of the whole system.
Applications:
◆Sound reinforcement for small and medium-sized places
◆High-quality music and vocal reinforcement
◆Movie theaters, churches, restaurants, recording studios, conference halls, multimedia classrooms Search
Model No. | HL2450 full range speaker |
Components | 2x4" (Φ25mm) |
Power | 80W(rated)/230W(program) |
Frequency response | 130Hz-25KHz |
Dispersion(H×V) | 90º ×60º |
Sensitivity(1W@1m) | 97dB |
Max. SPL | 118dB |
Nominal Impedance | 8Ω |
Dimensions(H×W×D)mm | |
Shipping(H×W×D)mm | |
NW/GW(kg) | 6.25/14.6(2pcs) |
Model No. | HL10B active subwoofer |
Components | 1 x 10" (Φ50mm) |
Power | 300W(rated)/1200W(program) |
Amplifier & DSP | 2*350W(8ohm) + 2in 4 out DSP |
Frequency Response | 500Hz-250Hz |
Sensitivity(1W@1m) | 95dB |
Max. SPL | 121dB |
Nominal Impedance | 4Ω |
Dimensions(H×W×D)mm | 266*490*540 |
Shipping(H×W×D)mm | |
NW/GW(kg) | 73/101.2 (4+1) |
