| receiver |
| Machine plug specifications | EIA standard IU |
| Channel combination | double channel |
| Frequency stability | ±0.005 rounds, PLL follows the same path frequency control |
| Smart wave band | UHF610-670MHZ |
| Modulation method | FH |
| Effective working distance | generally 50 meters (open space) |
| Oscillation mode | PLL phase-locked vibration synthesis |
| Sensitivity | 5dBuV,$/N>60dB at 25 deviation |
| Bandwidth frequency | 60MHz |
| Total shock wave distortion | <D.4@1KHz |
| Comprehensive frequency response | 65Hz ~ 18KHz ± 3dB |
| Power supply | DC12V1A |
| transmitter |
| Carrier frequency band | UHF610-670 MHz |
| Oscillation mode | PPL phase locked frequency synthesis |
| Harmonic radiation | <-63dBm |
| Bandwidth | 60 MHz |
| Maximum deviation range | ±45kHz |
| Microphone mode | capacitive (head-mounted/lavalier), dynamic coil (handheld), cardioid |
| RF power output | 8mW; 8mW/15mW (optional) |
| Battery | AAX2 |
| Current consumption | 110mA |
| Battery current/life | about 8 hours |
