Through the unremitting efforts of R & D engineers, the A series power amplifiers have carried out in-depth and meticulous screening of raw materials, careful comparison, and continuous industrial testing and aging, to achieve high damping coefficient
1. The equipment is safer and excellent convection cooling system
2. The new circuit design greatly improves the working efficiency of the machine
3. Perfect phase response and ultra-wide frequency response
4. The LED indication and the working status is clear at a glance
5. Professional HI--FI (high fidelity) design, the sound performance is real and natural
6. Extremely high industrial design requirements, reasonable layout, safe and reliable, and simple mechanism of the whole machine
| Model | A204 | A206 | A208 |
| 8Ω Stereo power(RMS) | 2×400W | 2×600W | 2×800W |
| 4Ω Stereo power(RMS) | 2×600W | 2×900W | 2×1200W |
| 8Ω bridge power(RMS) | 800W | 1600W | 1900W |
| Frequency Response | 20Hz-20KHz ±0.5% | ||
| Slew Rate | 30V/μs | ||
| THD(20Hz-20KHz) | ≤0.05% | ||
| Damping Factor | >280 | ||
| S/N(broad band width) | ≥102dB | ||
| Input Impedance | Balanced: 20KΩ; Unbalanced: 10KΩ | ||
| Input Sensitivity | 1Vrms | ||
| Input connector | 2 x XLR female | ||
| Link socket | 2 x XLR male | ||
| Output socket | 2 x Speakon | ||
| Class | H | ||
| IMD(rated power) | ≤0.05% | ||
| Mains | AC110V-240V/50-60Hz | ||
| Dimension(H*W*D) | 88×480×375mm | ||
| Shipping(H*W*D) | 142×585×520(0.04CBM)mm | ||
| Net Weight(KG) | 15.7 | 19 | 20.1 |
| Gross Weight(KG) | 18.6 | 21 | 22.4 |
